2V0-41.23 Online Practice Questions and Answers

Correct Answer: D

The Traceflow tool identifies issues in a network by injecting synthetic traffic into the data plane and observing the results in the control plane. This allows the tool to identify any issues in the network and provide a detailed report on the problem. You can use the Traceflow tool to test connectivity between any two endpoints in your NSX-T Data Center environment.

Correct Answer: B

Federation is a feature of NSX that allows the administrator to manage multiple NSX instances with a single pane of glass view, create gateways and segments that span one or more locations, and configure and enforce firewall rules consistently across locations1. Federation provides centralized policy management for security and networking services for all locations and pushes it down to NSX Local Managers at the respective sites for enforcement1. Federation also enables disaster recovery and workload mobility scenarios by providing consistent network and security policies across different sites1. References: 1: NSX Federation-VMware Docs(https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.2/administration/GUID-D5B6DC79-6733-44A7-8072-50221CF2122A.html)

Correct Answer: C

The NSX Manager management plane communicates with the transport nodes by using APH Server over NSX-RPC/TCP through port 1234. CCP communicates with the transport nodes by using APH Server over NSX-RPC/TCP through port 1235. Reference: https://docs.vmware.com/en/VMware-NSX/4.1/installation/GUID-FD3140B2-81BD-4FE7-9A23-4EB55B4E3099.html

Correct Answer: D

https://docs.vmware.com/en/VMware-NSX/4.0/administration/GUID-D57429A1-A0A9-42BE-A299-0C3C3546ABF3.html

Correct Answer: BE

According to the VMware NSX Documentation, these are two NAT rule types that are supported for a tier-0 gateway configured in active-standby high availability mode. NAT stands for Network Address Translation and is a feature that allows

you to modify the source or destination IP address of a packet as it passes through a gateway. Destination NAT: This rule type allows you to change the destination IP address of a packet from an external IP address to an internal IP address.

You can use this rule type to provide access to your internal servers from external networks using public IP addresses.

Source NAT: This rule type allows you to change the source IP address of a packet from an internal IP address to an external IP address. You can use this rule type to provide access to external networks from your internal servers using

public IP addresses.

Correct Answer: B

SNAT stands for Source Network Address Translation. It is a type of NAT that translates the source IP address of outgoing packets from a private address to a public address. SNAT is used to allow hosts in a private network to access the internet or other public networks1 In the exhibit, the administrator wants to change the private IP address of the NAT VM 172.16.101.11 to a public address of 80.80.80.1 as the packets leave the NAT-Segment network. This is an example of SNAT, as the source IP address is modified before the packets are sent to an external network. According to the VMware NSX 4.x Professional uide, SNAT is one of the topics covered in the exam objectives2 To learn more about SNAT and how to configure it in VMware NSX, you can refer to the following resources: VMware NSX Documentation: NAT 3 VMware NSX 4.x Professional: NAT Configuration 4 VMware NSX 4.x Professional: NAT Troubleshooting 5

https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.2/administration/GUID-7AD2C384-4303-4D6C-A44A-DEF45AA18A92.html

Correct Answer: D

The field in a Tier-1 Gateway Firewall that would be used to allow access for a collection of trustworthy web sites is Profiles-> L7 Access Profile. This field allows the user to create a Layer 7 access profile that defines a list of allowed or blocked URLs based on categories, reputation, or custom entries1. The user can then apply the L7 access profile to a firewall rule to control the traffic based on the URL filtering criteria1. The other options are incorrect because they are not related to URL filtering. The Source field specifies the source IP address or group of the firewall rule1. The Destination field specifies the destination IP address or group of the firewall rule1. The Profiles-> Context Profiles field allows the user to create a context profile that defines a list of application signatures or attributes that can be used to identify and classify network traffic1. References: Gateway Firewall

Correct Answer: D

According to the VMware NSX Documentation, this is the NSX feature that can be leveraged to achieve consistent policy configuration and simplicity across sites:

NSX Federation: This feature allows you to create and manage a global network infrastructure that spans across multiple sites using a single pane of glass. You can use this feature to synchronize policies, segments, gateways, firewalls,

VPNs, load balancers, and other network services across sites.

Correct Answer: BC

The two interfaces that will be used for ingress traffic on the Edge node supporting a Single Tier topology are:

B. Tier-0 Uplink interface

C. Downlink Interface for the Tier-0 DR The Tier-0 Uplink interface is the interface that connects the Tier-0 gateway to the external network. It is used to receive traffic from the physical router or switch that is the next hop for the Tier-0 gateway. The Tier-0 Uplink interface can be configured with a static IP address or use BGP to exchange routes with the external network. The Downlink Interface for the Tier-0 DR is the interface that connects the Tier-0 gateway to the workload segments. It is used to receive traffic from the VMs or containers that are attached to the segments. The Downlink Interface for the Tier-0 DR is a logical interface (LIF) that is distributed across all transport nodes that host the segments. The Downlink Interface for the Tier-0 DR has an IP address that acts as the default gateway for the VMs or containers on the segments.

Correct Answer: B

From the NSX UI the status of the VMware Identity Manager Integration must be "Enabled". According to the VMware NSX Documentation1, after configuring VMware Identity Manager integration, you can validate the functionality by checking the status of the integration in the NSX UI. The status should be "Enabled" if the integration is successful. The other options are either incorrect or not relevant.
