350-401 Online Practice Questions and Answers
SIMULATION
Guidelines
This is a lab item in which tasks will be performed on virtual devices.
1.
Refer to the Tasks tab to view the tasks for this lab item.
2.
Refer to the Topology tab to access the device console(s) and perform the tasks.
3.
Console access is available for all required devices by clicking the device icon or using the tab(s) above the console window.
4.
All necessary preconfigurations have been applied.
5.
Do not change the enable password or hostname for any device.
6.
Save your configurations to NVRAM before moving to the next item.
7.
Click Next at the bottom of the screen to submit this lab and move to the next question.
8.
When Next is clicked, the lab closes and cannot be reopened.
Topology
Tasks
The operations team started configuring network devices for a new site. R10 and R20 are preconfigured with the CORP VRF. R10 has network connectivity to R20. Complete the configurations to achieve these goals:
1.
Extend the CORP VRF between R10 and R20 using Tunnel0.
2.
Protect Tunnel0 using the preconfigured profile
3.
Configure static routing on R10 and R20 so that users in VLANs100 and 101 that belong to the CORP VRF are able to communicate with each other. Tunnel0 should be the only interface used to route traffic for the CORP VRF
A. See the solution below in Explanation.
B. Place Holder
C. Place Holder
D. Place Holder
Which network devices secure API platform?
A. next-generation intrusion detection systems
B. Layer 3 transit network devices
C. content switches
D. web application firewalls
Which three resources must the hypervisor make available to the virtual machines? (Choose three)
A. memory
B. bandwidth
C. IP address
D. processor
E. storage
F. secure access
Refer to the exhibit.
The traceroute fails from R1 to R3. What is the cause of the failure?
A. The loopback on R3 Is in a shutdown stale.
B. An ACL applied Inbound on loopback0 of R2 Is dropping the traffic.
C. An ACL applied Inbound on fa0/1 of R3 is dropping the traffic.
D. Redistribution of connected routes into OSPF is not configured.
By default, which virtual MAC address does HSRP group 30 use?
A. 00:05:0c:07:ac:30
B. 00:00:0c:07:ac:1e
C. 05:0c:5e:ac:07:30
D. 00:42:18:14:05:1e
Which statement explains why Type 1 hypervisor is considered more efficient than Type 2 hypervisor?
A. Type 1 hypervisor runs directly on the physical hardware of the host machine without relying on the underlying OS.
B. Type 1 hypervisor enables other operating systems to run on it.
C. Type 1 hypervisor relics on the existing OS of the host machine to access CPU, memory, storage, and network resources.
D. Type 1 hypervisor is the only type of hypervisor that supports hardware acceleration techniques.
Which NGFW mode blocks flows crossing the firewall?
A. tap
B. inline
C. passive
D. inline tap
Refer to the exhibit.
An engineer must ensure that all traffic leaving AS 200 will choose Link 2 as the exit point. Assuming that all BGP neighbor relationships have been formed and that the attributes have not been changed on any of the routers.
Which configuration accomplish task?
A. R4(config-router)bgp default local-preference 200
B. R3(config-router)neighbor 10.1.1.1 weight 200
C. R3(config-router)bgp default local-preference 200
D. R4(config-router)nighbor 10.2.2.2 weight 200
A network engineer attempts to connect to the Router1 console port.
Which configuration is needed to allow Telnet connections?
A. Router1(config)# line vty 0 15 Router1(config-line)# transport output telnet
B. Router1(config)# telnet client
C. Router1(config)# line console 0 Router1(config-line)# transport output telnet
D. Router1(config)# access-list 100 permit tcp any any eq telnet Router1(config)# line console 0 Router1(config-line)# access-class 100 out
Which Cisco DNA Center Assurance feature verifies host reachability?
A. path trace
B. application experience
C. detail information
D. network time travel
