350-801 Online Practice Questions and Answers

A customer wants a video conference with five Cisco TelePresence IX5000 Series systems. Which media resource is necessary in the design to fully utilize the immersive functions?

A. Cisco PVDM4-128

B. software conference bridge on Cisco Unified Communications Manager

C. Cisco Webex Meetings Server

D. Cisco Meeting Server

Why would we not include an end user's PC device in a QoS trust boundary?

A. The end user could incorrectly tag their traffic to bypass firewalls.

B. The end user may incorrectly tag their traffic to be prioritized over other network traffic.

C. There is no reason not to include an end user's PC device in a QoS trust boundary.

D. The end user could incorrectly tag their traffic to advertise their PC as a default gateway.

A Cisco collaboration engineer is troubleshooting unexpected SIP call disconnect. Which three responses corresponding to the 5xx range? (Choose Three)

A. Forbidden

B. Unauthorized

C. Request timeout

D. Service unavailable

E. Bad gateway

F. Internal server error

What is the correct statement about CUCM and Cisco IMandP backups?

A. Backups should the scheduled during hours to avoid system performance issues.

B. Backups are saved as .tar files and encrypted using the web administrator account.

C. Backups are saved as unencrypted tar files.

D. Backups are not needed for subscriber Cisco Unified Communication Manager and Cisco IM and Presence servers.

Which service on the Presence Server is responsible for maintaining the point-to-point chat connections between Jabber clients?

A. Cisco SIP Proxy

B. Cisco XCP Text Conference Manager

C. Cisco XCP Router

D. Cisco XCP XMPP Federation Manager

What are two differences between media flow-around and media flow-through on cisco unified Border element? (Choose two.)

A. When using media flow-through, the call signaling and media are passed through the Cisco Unified Border Element

B. When using media flow-through, the call signaling goes through the Cisco Unified Border Element, but media is not passed through it

C. When using media flow-around. the call signaling goes through the Cisco Unified Border Element, but media is not passed through it

D. When using media flow-around, both call signaling and media do not go through the Cisco Unified Border Element

E. When using media flow-through, call signaling goes through the Cisco Unified Border Element but media does not

In an eleven-class queueing model following Realtime. Best effort, and scavenger queuing rules. What recommended percentage of bandwidth must be allocated for interactive video?

A. 10%

B. 12%

C. 15%

D. 20%

Which two media encryptions should be used when configuring SRTP between Cisco UCM and Cisco VCS Expressway? (Choose two.)

A. optional

B. pass-through

C. priority

D. mandatory

E. none

An engineer must configure DTMF relay on a Cisco Unified Border Element by using RFC2833 as the preferred relay mechanism and KPML as the next preferred relay mechanism. The engineer logs in to the CUBE and enters the dial-peer configuration level. Which command should be run at the dial-peer configuration level?

A. dtmf-relay sip-kpml rtp-nte

B. dtmf-relay rtp-inband sip-kpml

C. dtmf-relay sip-kpml rtp-inband

D. dtmf-relay rtp-nte sip-kpml

All calls that involve external parties must be based on a format to simplify the International multisite dial plans when globalized call routing is used. Which standard must be followed to implement normalized call routing?

A. Internal to External Calling-party number: E.164 Called-party number: E.164

B. External to Internal Calling-party number: E.164 Called-party number: E.164

C. External (local number) to Internal Calling-party number: E.164 Called-party number: E.164 (localized, subscriber)

D. Internal to External (local number) Calling-party number: E.164 (localized, subscriber) Called-party number: E.164
