HP2-T26 Online Practice Questions and Answers

What is needed to connect a Windows-based laptop to the c7000 or c3000 enclosure service port and successfully communicate with the Onboard Administrator?

A. a laptop with the network interface set to DHCP and a null modem cable

B. a laptop with the network interface set to DHCP and a standard CAT5 patch cable

C. a laptop with the network interface set to an address in the 192.168.1.x range and a CAT5 crossover cable

D. a laptop with the network interface set to an address in the 192.168.1.x range and a standard CAT5 patch cable

Your customer used RAID 1+0, lost two drives, and the array failed. What can you recommend to better address the need for any two drive failures at the same time?

A. RAID 1

B. RAID 5

C. RAID 6

D. RAID 10

While troubleshooting a problem, you need to get a report from a ProLiant BL460c Gen8 Server detailing the firmware and driver revisions. Which report should you obtain?

A. Active Health Logs

B. Array Diagnostics Report

C. ILO Event Logs

D. Integrated Management Log

An engineer needs to install a UPS R8000/3 in an HP 10636 G2 rack. The rack already has one c7000 enclosure installed at the bottom of the rack.

What is the best location for the UPS R8000/3 installation?

A. Install the UPS R8000/3 in a dedicated rack.

B. Mount the UPS R8000/3 at the bottom of the rack and install the c7000 just above the UPS.

C. Install the UPS R8000/3 at the top of the rack for proper weight load balancing.

D. Install the UPS R8000/3 just above the c7000 enclosure in the rack.

Why should an electrostatic discharge (ESD) wrist strap be used when replacing parts such as memory DIMMs?

A. ESD protection is built into the equipment, so an ESC wrist strap is not needed.

B. A 48 V DC PSU will contribute to higher static electricity.

C. It prevents the part from being damaged by static electricity.

D. A current of more than 75 mlcan kill someone.

What is the maximum number of c3000 enclosures that can be installed in a 42U rack?

A. 4

B. 5

C. 6

D. 7

When should a performance baseline be captured?

A. after the initial installation of the equipment, during normal daily operation

B. after the initial installation of the equipment, during peak operating conditions

C. before and after each step of the initial installation of the equipment

D. three times a day during the first week following the initial installation of the equipment

What should you do to replace a defective Standby Onboard Administrator (OA) in a c7000 enclosure?

A. Move the Active OA to Standby bay, then replace the OA.

B. Replace the Standby OA after all server blades are powered off.

C. Replace the Standby OA only while the enclosure is powered off.

D. Replace the Standby OA while the enclosure is powered on.

What is the default ASR timer value after the HP Server Health driver is loaded?

A. 10 seconds

B. 10 minutes

C. 1 minute

D. 1 hour

A customer has a ProLiant BL680c G5 running a database application that crashes when one of the eight installed memory modules fails. The bad memory is replaced. How can the failure be prevented in the future?

A. by changing the memory configuration to RAID 5 memory

B. by installing Dual Ranked Memories for redundancy

C. by adding eight more DIMMs and using memory mirroring

D. by installing memory in all slots for a total of 256GB
