NSE7_EFW-6.2 Online Practice Questions and Answers

Examine the IPsec configuration shown in the exhibit; then answer the question below. Questions and Answers PDF P-3

An administrator wants to monitor the VPN by enabling the IKE real time debug using these commands: diagnose vpn ike log-filter src-addr4 10.0.10.1 diagnose debug application ike -1 diagnose debug enable The VPN is currently up, there is no traffic crossing the tunnel and DPD packets are being interchanged between both IPsec gateways. However, the IKE real time debug does NOT show any output.

Why isn't there any output?

A. The IKE real time shows the phases 1 and 2 negotiations only. It does not show any more output once the tunnel is up.

B. The log-filter setting is set incorrectly. The VPN's traffic does not match this filter.

C. The IKE real time debug shows the phase 1 negotiation only. For information after that, the administrator must use the IPsec real time debug instead: diagnose debug application ipsec -1.

D. The IKE real time debug shows error messages only. If it does not provide any output, it indicates that the tunnel is operating normally.

An administrator is running the following sniffer in a FortiGate: diagnose sniffer packet any "host 10.0.2.10" 2

What information is included in the output of the sniffer? (Choose two.)

A. Ethernet headers.

B. IP payload.

C. IP headers.

D. Port names.

View the central management configuration shown in the exhibit, and then answer the question below.

Which server will FortiGate choose for antivirus and IPS updates if 10.0.1.243 is experiencing an outage?

A. 10.0.1.240

B. One of the public FortiGuard distribution servers

C. 10.0.1.244

D. 10.0.1.242

View the exhibit, which contains the output of diagnose sys session list, and then answer the question below.

If the HA ID for the primary unit is zero (0), which statement is correct regarding the output?

A. This session is for HA heartbeat traffic.

B. This session is synced with the slave unit.

C. The inspection of this session has been offloaded to the slave unit.

D. This session cannot be synced with the slave unit.

What is the purpose of an internal segmentation firewall (ISFW)?

A. It inspects incoming traffic to protect services in the corporate DMZ.

B. It is the first line of defense at the network perimeter.

C. It splits the network into multiple security segments to minimize the impact of breaches.

D. It is an all-in-one security appliance that is placed at remote sites to extend the enterprise network.

View the following FortiGate configuration.

All traffic to the Internet currently egresses from port1. The exhibit shows partial session information for Internet traffic from a user on the internal network:

If the priority on route ID 1 were changed from 5 to 20, what would happen to traffic matching that user's session?

A. The session would remain in the session table, and its traffic would still egress from port1.

B. The session would remain in the session table, but its traffic would now egress from both port1 and port2.

C. The session would remain in the session table, and its traffic would start to egress from port2.

D. The session would be deleted, so the client would need to start a new session.

Examine the output from the 'diagnose debug authd fsso list' command; then answer the question below. # diagnose debug authd fsso list --FSSO logons-IP: 192.168.3.1 User: STUDENT Groups: TRAININGAD/USERS Workstation: INTERNAL2. TRAINING. LAB The IP address 192.168.3.1 is NOT the one used by the workstation INTERNAL2. TRAINING. LAB.

What should the administrator check?

A. The IP address recorded in the logon event for the user STUDENT.

B. The DNS name resolution for the workstation name INTERNAL2. TRAINING. LAB.

C. The source IP address of the traffic arriving to the FortiGate from the workstation INTERNAL2. TRAINING. LAB.

D. The reserve DNS lookup forthe IP address 192.168.3.1.

Examine the following routing table and BGP configuration; then answer the question below.

TheBGP connection is up, but the local peer is NOT advertising the prefix 192.168.1.0/24. Which configuration change will make the local peer advertise this prefix?

A. Enable the redistribution of connected routers into BGP.

B. Enable the redistribution of static routers into BGP.

C. Disable the setting network-import-check.

D. Enable the setting ebgp-multipath.

Which two configuration settings change the behavior for content-inspected traffic while FortiGate is in conserve mode? (Choose two.)

A. IPS failopen

B. mem failopen

C. AV failopen

D. UTM failopen

Refer to the exhibit, which contains the output of a BGP debug command.

Which statement about the exhibit is true?

A. The local router has received a total of three BGP prefixes from all peers.

B. The local router has not established a TCP session with 100.64.3.1.

C. Since the counters were last reset, the 10.200.3.1 peer has never been down.

D. The local router BGP state is OpenConfirm with the 10.127.0.75 peer.
