NSE7_EFW-6.4 Online Practice Questions and Answers

Two independent FortiGate HA clusters are connected to the same broadcast domain. The administrator has reported that both clusters are using the same HA virtual MAC address. This creates a duplicated MAC address problem in the network. What HA setting must be changed in one of the HA clusters to fix the problem?

A. Group ID.

B. Group name.

C. Session pickup.

D. Gratuitous ARPs.

Refer to the exhibit, which contains partial output from an IKE real-time debug.

Based on the debug output, which phase 1 setting is enabled in the configuration of this VPN?

A. auto-discovery-shortcut

B. auto-discovery-forwarder

C. auto-discovery-sender

D. auto-discovery-receiver

View the exhibit, which contains the output of a debug command, and then answer the question below.

Which one of the following statements about this FortiGate is correct?

A. It is currently in system conserve mode because of high CPU usage.

B. It is currently in extreme conserve mode because of high memory usage.

C. It is currently in proxy conserve mode because of high memory usage.

D. It is currently in memory conserve mode because of high memory usage.

A FortiGate device has the following LDAP configuration: The LDAP user student cannot authenticate. The exhibit shows the output of the authentication real time debug while testing the student account:

Based on the above output, what FortiGate LDAP settings must the administer check? (Choose two.)

A. cnid.

B. username.

C. password.

D. dn.

View the exhibit, which contains a screenshot of some phase-1 settings, and then answer the question below.

The VPN is up, and DPD packets are being exchanged between both IPsec gateways; however, traffic cannot pass through the tunnel. To diagnose, the administrator enters these CLI commands:

However, the IKE real time debug does not show any output. Why?

A. The debug output shows phases 1 and 2 negotiations only. Once the tunnel is up, it does not show any more output.

B. The log-filter setting was set incorrectly. The VPN's traffic does not match this filter.

C. The debug shows only error messages. If there is no output, then the tunnel is operating normally.

D. The debug output shows phase 1 negotiation only. After that, the administrator must enable the following real time debug: diagnose debug application ipsec -1.

Which of the following conditions must be met for a static route to be active in the routing table? (Choose three.)

A. The next-hop IP address is up.

B. There is no other route, to the same destination, with a higher distance.

C. The link health monitor (if configured) is up.

D. The next-hop IP address belongs to one of the outgoing interface subnets.

E. The outgoing interface is up.

Refer to the exhibit, which contains the output of a BGP debug command.

Which statement about the exhibit is true?

A. The local router has received a total of three BGP prefixes from all peers.

B. The local router has not established a TCP session with 100.64.3.1.

C. Since the counters were last reset, the 10.200.3.1 peer has never been down.

D. The local router BGP state is OpenConfirm with the 10.127.0.75 peer.

When does a RADIUS server send an Access-Challenge packet?

A. The server does not have the user credentials yet.

B. The server requires more information from the user, such as the token code for two- factor authentication.

C. The user credentials are wrong.

D. The user account is not found in the server.

Examine the output of the 'diagnose debug rating' command shown in the exhibit; then answer the question below.

Which statement are true regarding the output in the exhibit? (Choose two.)

A. There are three FortiGuard servers that are not responding to the queries sent by the FortiGate.

B. The TZ value represents the delta between each FortiGuard server's time zone and the FortiGate's time zone.

C. FortiGate will send the FortiGuard queries to the server with highest weight.

D. A server's round trip delay (RTT) is not used to calculate its weight.

A FortiGate's portl is connected to a private network. Its port2 is connected to the Internet. Explicit web proxy is enabled in port1 and only explicit web proxy users can access the Internet. Web cache is NOT enabled. An internal web proxy user is downloading a file from the Internet via HTTP. Which statements are true regarding the two entries in the FortiGate session table related with this traffic? (Choose two.)

A. Both session have the local flag on.

B. The destination IP addresses of both sessions are IP addresses assigned to FortiGate's interfaces.

C. One session has the proxy flag on, the other one does not.

D. One of the sessions has the IP address of port2 as the source IP address.
