NSE8_812 Online Practice Questions and Answers
SD-WAN is configured on a FortiGate. You notice that when one of the internet links has high latency the time to resolve names using DNS from FortiGate is very high.
You must ensure that the FortiGate DNS resolution times are as low as possible with the least amount of work. What should you configure?
A. Configure local out traffic to use the outgoing interface based on SD-WAN rules with a manual defined IP associated to a loopback interface and configure an SD-WAN rule from the loopback to the DNS server.
B. Configure an SD-WAN rule to the DNS server and use the FortiGate interface IPs in the source address.
C. Configure two DNS servers and use DNS servers recommended by the two internet providers.
D. Configure local out traffic to use the outgoing interface based on SD-WAN rules with the interface IP and configure an SD-WAN rule to the DNS server.
Refer to the exhibit showing the history logs from a FortiMail device.
Which FortiMail email security feature can an administrator enable to treat these emails as spam?
A. DKIM validation in a session profile
B. Sender domain validation in a session profile
C. Impersonation analysis in an antispam profile
D. Soft fail SPF validation in an antispam profile
Review the VPN configuration shown in the exhibit.
What is the Forward Error Correction behavior if the SD-WAN network traffic download is 500 Mbps and has 8% of packet loss in the environment?
A. 1 redundant packet for every 10 base packets
B. 3 redundant packet for every 5 base packets
C. 2 redundant packet for every 8 base packets
D. 3 redundant packet for every 9 base packets
Refer to the exhibit.
To facilitate a large-scale deployment of SD-WAN/ADVPN with FortiGate devices, you are tasked with configuring the FortiGate devices to support injecting of IKE routes on the ADVPN shortcut tunnels. Which three commands must be added or changed to the FortiGate spoke config vpn ipsec phasei-interface options referenced in the exhibit for the VPN interface to enable this capability? (Choose three.)
A. set net-device disable
B. set mode-cfg enable
C. set ike-version 1
D. set add-route enable
E. set mode-cfg-allow-client-selector enable
Refer to the exhibit, which shows a VPN topology.
The device IP 10.1.100.40 downloads a file from the FTP server IP 192.168.4.50
Referring to the exhibit, what will be the traffic flow behavior if ADVPN is configured in this environment?
A. All the session traffic will pass through the Hub
B. The TCP port 21 must be allowed on the NAT Device2
C. ADVPN is not supported when spokes are behind NAT
D. Spoke1 will establish an ADVPN shortcut to Spoke2
You are running a diagnose command continuously as traffic flows through a platform with NP6 and you obtain the following output: Given the information shown in the output, which two statements are true? (Choose two.)
A. Enabling bandwidth control between the ISF and the NP will change the output
B. The output is showing a packet descriptor queue accumulated counter
C. Enable HPE shaper for the NP6 will change the output
D. Host-shortcut mode is enabled.
E. There are packet drops at the XAUI.
A customer's cybersecurity department needs to implement security for the traffic between two VPCs in AWS, but these belong to different departments within the company. The company uses a single region for all their VPCs.
Which two actions will achieve this requirement while keeping separate management of each department's VPC? (Choose two.)
A. Create a transit VPC with a FortiGate HA cluster, connect to the other two using VPC peering, and use routing tables to force traffic through the FortiGate cluster.
B. Create an 1AM account for the cybersecurity department to manage both existing VPC, create a FortiGate HA Cluster on each VPC and IPSEC VPN to force traffic between the VPCs through the FortiGate clusters
C. Migrate all the instances to the same VPC and create 1AM accounts for each department, then implement a new subnet for a FortiGate auto-scaling group and use routing tables to force the traffic through the FortiGate cluster.
D. Create a VPC with a FortiGate auto-scaling group with a Transit Gateway attached to the three VPC to force routing through the FortiGate cluster
Refer to the exhibit, which shows the high availability configuration for the FortiAuthenticator (FAC1).
Based on this information, which statement is true about the next FortiAuthenticator (FAC2) member that will join an HA cluster with this FortiAuthenticator (FAC1)?
A. FAC2 can only process requests when FAC1 fails.
B. FAC2 can have its HA interface on a different network than FAC1.
C. The FortiToken license will need to be installed on the FAC2.
D. FSSO sessions from FAC1 will be synchronized to FAC2.
A remote IT Team is in the process of deploying a FortiGate in their lab. The closed environment has been configured to support zero-touch provisioning from the FortiManager, on the same network, via DHCP options. After waiting 15 minutes, they are reporting that the FortiGate received an IP address, but the zero-touch process failed.
The exhibit below shows what the IT Team provided while troubleshooting this issue:
Which statement explains why the FortiGate did not install its configuration from the FortiManager?
A. The FortiGate was not configured with the correct pre-shared key to connect to the FortiManager
B. The DHCP server was not configured with the FQDN of the FortiManager
C. The DHCP server used the incorrect option type for the FortiManager IP address.
D. The configuration was modified on the FortiGate prior to connecting to the FortiManager
You are deploying a FortiExtender (FEX) on a FortiGate-60F. The FEX will be managed by the FortiGate. You anticipate high utilization. The requirement is to minimize the overhead on the device for WAN traffic.
Which action achieves the requirement in this scenario?
A. Add a switch between the FortiGate and FEX.
B. Enable CAPWAP connectivity between the FortiGate and the FortiExtender.
C. Change connectivity between the FortiGate and the FortiExtender to use VLAN Mode
D. Add a VLAN under the FEX-WAN interface on the FortiGate.
