PROFESSIONAL-CLOUD-NETWORK-ENGINEER Online Practice Questions and Answers

You are migrating to Cloud DNS and want to import your BIND zone file. Which command should you use?

A. gcloud dns record-sets import ZONE_FILE --zone MANAGED_ZONE

B. gcloud dns record-sets import ZONE_FILE --replace-origin-ns --zone MANAGED_ZONE

C. gcloud dns record-sets import ZONE_FILE --zone-file-format --zone MANAGED_ZONE

D. gcloud dns record-sets import ZONE_FILE --delete-all-existing --zone MANAGED ZONE

You need to establish network connectivity between three Virtual Private Cloud networks, Sales, Marketing, and Finance, so that users can access resources in all three VPCs. You configure VPC peering between the Sales VPC and the Finance VPC. You also configure VPC peering between the Marketing VPC and the Finance VPC. After you complete the configuration, some users cannot connect to resources in the Sales VPC and the Marketing VPC. You want to resolve the problem.

What should you do?

A. Configure VPC peering in a full mesh.

B. Alter the routing table to resolve the asymmetric route.

C. Create network tags to allow connectivity between all three VPCs.

D. Delete the legacy network and recreate it to allow transitive peering.

Your organization's security policy requires that all internet-bound traffic return to your on-premises data center through HA VPN tunnels before egressing to the internet, while allowing virtual machines (VMs) to leverage private Google APIs

using private virtual IP addresses 199.36.153.4/30. You need to configure the routes to enable these traffic flows.

What should you do?

A. Configure a custom route 0.0.0.0/0 with a priority of 500 whose next hop is the default internet gateway. Configure another custom route 199.36.153.4/30 with priority of 1000 whose next hop is the VPN tunnel back to the on-premises data center.

B. Configure a custom route 0.0.0.0/0 with a priority of 1000 whose next hop is the internet gateway. Configure another custom route 199.36.153.4/30 with a priority of 500 whose next hop is the VPN tunnel back to the on-premises data center.

C. Announce a 0.0.0.0/0 route from your on-premises router with a MED of 1000. Configure a custom route 199.36.153.4/30 with a priority of 1000 whose next hop is the default internet gateway.

D. Announce a 0.0.0.0/0 route from your on-premises router with a MED of 500. Configure another custom route 199.36.153.4/30 with a priority of 1000 whose next hop is the VPN tunnel back to the on-premises data center.

You need to create the network infrastructure to deploy a highly available web application in the us-east1 and us-west1 regions. The application runs on Compute Engine instances, and it does not require the use of a database. You want to follow Google-recommended practices. What should you do?

A. Create one VPC with one subnet in each region. Create a regional network load balancer in each region with a static IP address. Enable Cloud CDN on the load balancers. Create an A record in Cloud DNS with both IP addresses for the load balancers.

B. Create one VPC with one subnet in each region. Create a global load balancer with a static IP address. Enable Cloud CDN and Google Cloud Armor on the load balancer. Create an A record using the IP address of the load balancer in Cloud DNS.

C. Create one VPC in each region, and peer both VPCs. Create a global load balancer. Enable Cloud CDN on the load balancer. Create a CNAME for the load balancer in Cloud DNS.

D. Create one VPC with one subnet in each region. Create an HTTP(S) load balancer with a static IP address. Choose the standard tier for the network. Enable Cloud CDN on the load balancer. Create a CNAME record using the load balancer's IP address in Cloud DNS.

You have a storage bucket that contains two objects. Cloud CDN is enabled on the bucket, and both objects have been successfully cached. Now you want to make sure that one of the two objects will not be cached anymore, and will always be served to the internet directly from the origin.

What should you do?

A. Ensure that the object you don't want to be cached anymore is not shared publicly.

B. Create a new storage bucket, and move the object you don't want to be checked anymore inside it. Then edit the bucket setting and enable the private attribute.

C. Add an appropriate lifecycle rule on the storage bucket containing the two objects.

D. Add a Cache-Control entry with value private to the metadata of the object you don't want to be cached anymore. Invalidate all the previously cached copies.

You are increasing your usage of Cloud VPN between on-premises and GCP, and you want to support more traffic than a single tunnel can handle. You want to increase the available bandwidth using Cloud VPN.

What should you do?

A. Double the MTU on your on-premises VPN gateway from 1460 bytes to 2920 bytes.

B. Create two VPN tunnels on the same Cloud VPN gateway that point to the same destination VPN gateway IP address.

C. Add a second on-premises VPN gateway with a different public IP address. Create a second tunnel on the existing Cloud VPN gateway that forwards the same IP range, but points at the new on-premises gateway IP.

D. Add a second Cloud VPN gateway in a different region than the existing VPN gateway. Create a new tunnel on the second Cloud VPN gateway that forwards the same IP range, but points to the existing on-premises VPN gateway IP address.

Your company recently migrated to Google Cloud in a Single region. You configured separate Virtual Private Cloud (VPC) networks for two departments. Department A and Department B. Department A has requested access to resources that are part Of Department Bis VPC. You need to configure the traffic from private IP addresses to flow between the VPCs using multi-NIC virtual machines (VMS) to meet security requirements Your configuration also must

1.

Support both TCP and UDP protocols

2.

Provide fully automated failover

3.

Include health-checks

Require minimal manual Intervention In the client VMS

Which approach should you take?

A. Create the VMS In the same zone, and configure static routes With IP addresses as next hops.

B. Create the VMS in different zones, and configure static routes with instance names as next hops

C. Create an Instance template and a managed instance group. Configure a Single internal load balancer, and define a custom static route with the Internal TCP/UDP load balancer as the next hop

D. Create an instance template and a managed instance group. Configure two separate internal TCP/IJDP load balancers for each protocol (TCP!UDP), and configure the client VIVIS to use the internal load balancers' virtual IP addresses

You are configuring load balancing for a standard three-tier (web, application, and database) application. You have configured an external HTTP(S) load balancer for the web servers. You need to configure load balancing for the application tier of servers. What should you do?

A. Configure a forwarding rule on the existing load balancer for the application tier.

B. Configure equal cost multi-path routing on the application servers.

C. Configure a new internal HTTP(S) load balancer for the application tier.

D. Configure a URL map on the existing load balancer to route traffic to the application tier.

You are responsible for designing a new connectivity solution for your organization's enterprise network to access and use Google Workspace. You have an existing Shared VPC with Compute Engine instances in us-west1. Currently, you access Google Workspace via your service provider's internet access. You want to set up a direct connection between your network and Google. What should you do?

A. Order a Dedicated Interconnect connection in the same metropolitan area. Create a VLAN attachment, a Cloud Router in us-west1, and a Border Gateway Protocol (BGP) session between your Cloud Router and your router.

B. Order a Direct Peering connection in the same metropolitan area. Configure a Border Gateway Protocol (BGP) session between Google and your router.

C. Configure HA VPN in us-west1. Configure a Border Gateway Protocol (BGP) session between your Cloud Router and your on-premises data center.

D. Order a Carrier Peering connection in the same metropolitan area. Configure a Border Gateway Protocol (BGP) session between Google and your router.

Your company has 10 separate Virtual Private Cloud (VPC) networks, with one VPC per project in a single region in Google Cloud. Your security team requires each VPC network to have private connectivity to the main on-premises location via a Partner Interconnect connection in the same region. To optimize cost and operations, the same connectivity must be shared with all projects. You must ensure that all traffic between different projects, on-premises locations, and the internet can be inspected using the same third-party appliances. What should you do?

A. Configure the third-party appliances with multiple interfaces and specific Partner Interconnect VLAN attachments per project. Create the relevant routes on the third-party appliances and VPC networks.

B. Configure the third-party appliances with multiple interfaces, with each interface connected to a separate VPC network. Create separate VPC networks for on-premises and internet connectivity. Create the relevant routes on the third-party appliances and VPC networks.

C. Consolidate all existing projects' subnetworks into a single VPC. Create separate VPC networks for on-premises and internet connectivity. Configure the third-party appliances with multiple interfaces, with each interface connected to a separate VPC network. Create the relevant routes on the third-party appliances and VPC networks.

D. Configure the third-party appliances with multiple interfaces. Create a hub VPC network for all projects, and create separate VPC networks for on-premises and internet connectivity. Create the relevant routes on the third-party appliances and VPC networks. Use VPC Network Peering to connect all projects' VPC networks to the hub VPC. Export custom routes from the hub VPC and import on all projects' VPC networks.
